LED Transformer 300W 24V Dimmable TRIAC 0-10V NV
LED Transformer 300W 24V Dimmable TRIAC 0-10V NV
Power Output: 300W
Input Voltage: 100–240V AC
Output Voltage: 24V DC
Output Current: up to 12.5A
Dimmable: Yes – TRIAC (phase cut) and 0-10V compatible
Cooling: Passive (fanless and silent)
Housing: Aluminum alloy, heat-resistant
Protections: Short circuit, overload, overheat, overvoltage
Use Case: Indoor (may vary with enclosure spec NV)
LED Transformer 300W 24V Dimmable TRIAC 0-10V NV . Silent, high-power LED driver for professional lighting systems and smart installations.
LED Transformer 300W 24V Dimmable TRIAC 0-10V NV
LED Transformer 300W 24V Dimmable TRIAC 0-10V NV is a premium-grade LED driver built to power and dim large LED lighting setups efficiently and safely. Whether you’re managing a commercial, industrial, or architectural project, this transformer offers the flexibility and power you need.
It supports both TRIAC dimming (leading/trailing edge) and 0-10V analog dimming, giving you full compatibility with various dimmer types and smart home systems. This makes it ideal for projects requiring precision brightness control.
The 300W output (24V DC) allows it to drive long LED strip runs, powerful LED panels, or multi-zone installations — all with consistent performance and stable, flicker-free light output.
With passive cooling (fanless) and built-in protections, it ensures silent operation, longevity, and maximum reliability.
⚙️ Technical Specifications:
Power Output: 300W
Input Voltage: 100–240V AC
Output Voltage: 24V DC
Output Current: up to 12.5A
Dimmable: Yes – TRIAC (phase cut) and 0-10V compatible
Cooling: Passive (fanless and silent)
Housing: Aluminum alloy, heat-resistant
Protections: Short circuit, overload, overheat, overvoltage
Use Case: Indoor (may vary with enclosure spec NV)
✅ Ideal Applications:
Long 24V LED strip runs
Large LED panels or fixtures
Retail, commercial, or hospitality lighting
Architectural lighting with dimming zones
Smart home or office environments
Theatrical, studio, or stage lighting
This transformer is the go-to choice for those who need high wattage, advanced dimming, and lasting performance in demanding LED projects.
| Current | 12.5A |
|---|---|
| Output (V) | DC 24V |
| Dimmable | Oui |
| Brand | DiamantLED |
| Dimensions | 287x49x21 mm |
| Matérial | Aluminium |
| Frequency | 50/60HZ |
